The MOIS warning system will alert at the right time and prevent accidents when the vehicle is starting or coasting slowly. Road users such as pedestrians, bicycles, and motorcycles are most likely to fall into blind corners. This warning system can ensure that even if the person or vehicle ahead is obscured, it can still detect and remind the driver.
Utilizes AI recognition to provide sound and light alerts to road users when a vehicle stops and starts moving to address blind spot areas. .
Installed in the front of the vehicle, it provides blind spot assistance when the vehicle starts to avoid collision accidents caused by blind spots in the driver's line of sight.
1. When the vehicle is stopped, there may be pedestrians passing by. When the large vehicle blocks the line of sight, the situation ahead cannot be noticed.
2. The MOIS system can detect areas where the front view is blocked by the large vehicle and provide real-time feedback on the screen and sound in the vehicle to avoid accidents.
1. When a large vehicle is waiting for a traffic light, there may be a situation where a bicycle or motorcycle is parked directly in front of the vehicle where the line of sight is blocked. The large vehicle may start directly because it does not see it.
2. The MOIS system can detect areas where the front view is blocked by the large vehicle and provide real-time feedback on the screen and sound in the vehicle to avoid accidents.
| MCU BOX system specifications | |
|---|---|
Model | MOIS |
Operating Voltage | DC 10~36V |
Power consumption | < 15W |
working conditions | 30~80% relative humidity/ -40℃~75℃ |
Storage conditions | 30~80% relative humidity/ -40℃~75℃ |
I/O interface | Indicator LED/Button/Buzzer/GPS/ACC/GND/Right Turn Indicator/Left Turn Indicator/Vehicle Speed/Trigger |
warning message | Audible warning (buzzer)/indicator LED |
| Camera specifications | |
|---|---|
Sensor format | CMOS |
Operating Voltage | DC 9~36V |
Working current | ~200mA@DC 12V |
Photosensitive element resolution | 1280x960 (720P) |
minimum illumination | 0.1lux |
signal-to-noise ratio | 42dB@12lux |
HDR | >100dB |
Image format | CVBS (1.0Vp-p/With 75Ω load) / AHD / TVI (can be selected by engineering mode) |
Sensing viewing angle | 180° |
Image output angle | H(horizontal):170° / V(vertical):125° |
waterproof level | IP69K |
Lens elements | 6G+IR |
I/O | RS485 |
spectrum | Dual band T50% 650/850nm |
working conditions | 30~80% relative humidity/ -40℃~85℃ |
Storage conditions | 30~80% relative humidity/-40℃~105℃ |
| Other component specifications | |
|---|---|
buzzer | 10cm/10Vp-p,square wave,4.1KHz. |
